Key Features
- Smooth horizontal sliding design, space-saving for indoor-outdoor access
- Two series available: Non Thermally Broken and Thermally Broken
- 2-Track (100mm frame) and 3-Track (150mm frame) configurations
- Heavy-duty 6063-T5 aluminium frame with high structural rigidity
- Reinforced roller system for quiet, durable long-term operation
- Full perimeter sealing for excellent air, water and wind resistance
- Multi-point locking system for high security and stability
- Fully compliant with Australian AS2047 and NCC building standards
Options & Customisation
- Frame Series: Non Thermally Broken / Thermally Broken
- Track Types: 2-Track 100mm Frame | 3-Track 150mm Frame
- Finishes: Powder coat, anodized, wood grain, dual-colour
- Glazing: Double / Triple glazing, Low-e, tinted, acoustic glass
- Hardware: Stainless steel rollers, key lock and security handles
- Fly screens: Integrated retractable or fixed fly screen options
- Custom sizes and multi-door combined assemblies
Applications
- Patio, balcony and alfresco areas in residential homes & villas
- Apartments, townhouses and multi-residential complexes
- Offices, retail shops, cafes and commercial premises
- Coastal areas, high wind zones and standard residential zones
- New builds, home extensions, renovations and facade upgrades
- Projects requiring large opening width and natural light
Technical Data — Non Thermally Broken
Model 1: 2-Track | 100mm Frame Depth
| Specification | Details |
|---|---|
| Frame Material | 6063-T5 Architectural Aluminium |
| Frame Depth | 100mm (Non Thermally Broken) |
| Track Type | 2-Track Sliding System |
| Glazing Thickness | 5mm ~ 12mm Single / Double Glazing |
| Max Leaf Size (H x W) | 2400mm x 1200mm |
| Max Leaf Weight | 120kg |
| Hardware | Heavy-duty stainless steel rollers & locks |
| Surface Finish | Powder coating / Anodized / Wood grain |
Model 2: 3-Track | 150mm Frame Depth
| Specification | Details |
|---|---|
| Frame Material | 6063-T5 Architectural Aluminium |
| Frame Depth | 150mm (Non Thermally Broken) |
| Track Type | 3-Track Sliding System |
| Glazing Thickness | 5mm ~ 12mm Single / Double Glazing |
| Max Leaf Size (H x W) | 2600mm x 1400mm |
| Max Leaf Weight | 150kg |
| Hardware | Reinforced stainless steel roller assembly |
| Surface Finish | Powder coating / Anodized / Wood grain |
Technical Data — Thermally Broken
Model 3: 2-Track | 100mm Frame Depth
| Specification | Details |
|---|---|
| Frame Material | 6063-T5 Aluminium with Polyamide Thermal Break |
| Frame Depth | 100mm (Thermally Broken) |
| Track Type | 2-Track Sliding System |
| Glazing Thickness | 6mm ~ 16mm Double / Triple Glazing |
| Max Leaf Size (H x W) | 2400mm x 1200mm |
| Max Leaf Weight | 120kg |
| Hardware | Premium stainless steel hardware set |
| Surface Finish | Powder coating / Anodized / Wood grain / Dual-colour |
Model 4: 3-Track | 150mm Frame Depth
| Specification | Details |
|---|---|
| Frame Material | 6063-T5 Aluminium with Polyamide Thermal Break |
| Frame Depth | 150mm (Thermally Broken) |
| Track Type | 3-Track Sliding System |
| Glazing Thickness | 6mm ~ 16mm Double / Triple Glazing |
| Max Leaf Size (H x W) | 2600mm x 1400mm |
| Max Leaf Weight | 150kg |
| Hardware | Heavy-duty premium stainless steel assembly |
| Surface Finish | Powder coating / Anodized / Wood grain / Dual-colour |
Performance Ratings (AS2047) — Non Thermally Broken
2-Track 100mm
Air Permeability
Class 4
Water Penetration
Class 4
Wind Load
AS/NZS 1170.2 High Wind Zone
Thermal Performance
Standard NCC Compliance
3-Track 150mm
Air Permeability
Class 4
Water Penetration
Class E750
Wind Load
AS/NZS 1170.2 High Wind Zone
Thermal Performance
Standard NCC Compliance
Performance Ratings (AS2047) — Thermally Broken
2-Track 100mm
Air Permeability
Class 4
Water Penetration
Class E750
Wind Load
AS/NZS 1170.2 Severe Wind Zone
Thermal Performance
Premium Energy Rating | NCC High Grade
3-Track 150mm
Air Permeability
Class 4
Water Penetration
Class E750
Wind Load
AS/NZS 1170.2 Severe Wind Zone
Thermal Performance
Premium Energy Rating | NCC High Grade
