Key Features
- Horizontal sliding operation, space-saving design
- Smooth rolling track system for quiet, effortless movement
- Multiple frame depths to suit different construction requirements
- Durable 6063-T5 aluminium frame with long service life
- Excellent air tightness and water resistance for Australian weather
- Corrosion-resistant stainless steel rollers and hardware
- Fully tested and compliant with Australian AS2047 standards
Options & Customisation
- Frame types: 60mm Non-Thermal, 100mm Non-Thermal, 100mm Thermal Break
- Full range of powder coat, anodized and wood grain finishes
- Single / Double glazing, Low-e, tinted and reflective glass
- Key lock handles and security locking systems
- Integrated fly screen and security screen solutions
- Custom sizes, 2-track, 3-track and multi-panel configurations
Applications
- Living rooms, bedrooms and hallways in residential homes
- Apartments, townhouses and multi-residential complexes
- Retail spaces, offices and commercial buildings
- Coastal areas, high-wind zones and suburban developments
- New builds, extensions and renovation projects nationwide
Technical Data by Frame Model
Model 1: 60mm Non Thermally Broken
| Specification | Details |
|---|---|
| Frame Material | 6063-T5 Architectural Aluminium |
| Frame Depth | 60mm (Non Thermally Broken) |
| Glazing Thickness | 5mm ~ 10mm Single / Double Glazing |
| Max Dimension (H x W) | 2100mm x 1800mm |
| Hardware | Stainless steel rollers & locking handles |
| Surface Finish | Powder coating / Anodized |
Model 2: 100mm Non Thermally Broken
| Specification | Details |
|---|---|
| Frame Material | 6063-T5 Architectural Aluminium |
| Frame Depth | 100mm (Non Thermally Broken) |
| Glazing Thickness | 5mm ~ 12mm Single / Double Glazing |
| Max Dimension (H x W) | 2400mm x 2400mm |
| Hardware | Heavy-duty stainless steel roller system |
| Surface Finish | Powder coating / Anodized / Wood grain |
Model 3: 100mm Thermally Broken
| Specification | Details |
|---|---|
| Frame Material | 6063-T5 Aluminium with Thermal Break |
| Frame Depth | 100mm (Thermally Broken) |
| Glazing Thickness | 6mm ~ 12mm Double / Triple Glazing |
| Max Dimension (H x W) | 2400mm x 2400mm |
| Hardware | Premium stainless steel sliding hardware |
| Surface Finish | Powder coating / Anodized / Wood grain |
Performance Ratings (AS2047) by Model
60mm Non Thermally Broken
Air Permeability
Class 3
Water Penetration
Class 3
Wind Load
AS/NZS 1170.2 General Zone
Thermal Performance
Standard NCC Compliance
100mm Non Thermally Broken
Air Permeability
Class 4
Water Penetration
Class 4
Wind Load
AS/NZS 1170.2 High Wind Zone
Thermal Performance
Enhanced NCC Compliance
100mm Thermally Broken
Air Permeability
Class 4
Water Penetration
Class 4
Wind Load
AS/NZS 1170.2 Severe Wind Zone
Thermal Performance
Premium Energy Rating | NCC High Grade
